Double Coil 26 to 55inch LED TV Constant current board ,LED TV universal inverter, LED TV backlight driver board
Double Coil 26 to 55inch LED TV Constant current board ,LED TV universal inverter, LED TV backlight driver board
Double Coil 26 to 55inch LED TV Constant current board ,LED TV universal inverter, LED TV backlight driver board
Double Coil 26 to 55inch LED TV Constant current board ,LED TV universal inverter, LED TV backlight driver board
Double Coil 26 to 55inch LED TV Constant current board ,LED TV universal inverter, LED TV backlight driver board

Double Coil 26 to 55inch LED TV Constant current board ,LED TV universal inverter, LED TV backlight driver board

Regular price Rs. 599.00 Sale price Rs. 299.00
Unit price  per
Tax included. Shipping calculated at checkout.

Led Lcd Driver and led TV back light driver board TV constant current board boost universal modification

Used for : 26inch-55inch LED TV

Input Voltage :19-45V DC    Output Voltage :60-165V DC

Output current: 10MA-1000MA (can set)

Size: 120x60mm

Item Description:

The LED Strip Vol must be between 60V-165's. Not less than 60V, if less than 60V ,
you can choose our other item..Not higher than 165V, the product design conditions
shall not exceed the maximum working voltage of 165V.If the voltage exceeds ,the screen
will appear dark or flashing lamp and so on. This product is only constant,
not constant voltage, the voltage will automatically adjust to the appropriate voltage
according to the led strip need,
so you do not worry about in no-load voltage condition  measuring how much voltage is.


You may meet the problems after correct lighting:
The brightness is not enough, the screen is significantly darker than the original’s .
now you need to do the two things :

First, attempt to use the remote control  after connected to the transfer barefoot
to try brightness, if not resolved,test the actual pin voltage (Note: it will be the
greatest brightness in 0V, the brightness will be the darkest in greatest Voltage) .

if it is an analog voltage mode voltage range is between 0V-5V or 0V-3.3V,
if the voltage has been in hight condition all the time andcan not be reduced ,
now you need to adjust it . the voltage is 3.3V if it is PWM signal ,
it still can be up to request if adjust to
the greatest brightness at this time ,you need to do second program

Second, adjusting the resistance , increases the current to meet the requirements.
